Electric Pallet Stacker ACL-10E/12E/15E/20E

Various capacity meet your requirement, 1.0t/1.2t/1.5t/2.0t

Bais walkie type, operator has very good overview

Middle drive type and straddle type are optional

Use lead-acid battery, long battery lift and working time

Side shift can be optional

ADD TO FAVORITES INQUIRY NOW

DESCRIPTION

FAQ

Model		ELES-10E / ES-12E						ELES-15E								ELES-20E
Operate type		Electric						Electric
Drive style		Walkie						Walkie
Capacity Q	kg	1000/1200						1500/2000
Load center C	mm	600						600
Overall length L1	mm	1815						1950						2050		1980
Overall width W	mm	800						840
Mast. lowered height H1	mm	2110	1800	2060	2210	2315	2560	2125	1800	2080	2220	2335	2560	2100	2265	2125	1800	2080
Fork size L×b×m	mm	1150×160×56						1150×160×56
Outside fork width D	mm	540/680						540/680
Min. ground clearance x	mm	29						29
Wheel base L0	mm	1250						1250						1415		1360
Wheel type		PU						PU
Size of driving wheel	mm	φ250×80						φ250×80
Size of loading whee	mm	φ78×70						φ78×70
Size of balance wheel	mm	φ125×75						φ125×75
Min. turning radius Wa	mm	1460						1550						1600		1560
Min. aisle width	mm	≥2150						≥2250						≥2500		≥2300
Lift height H	mm	1600	2500	3000	3300	3500	4000	1600	2500	3000	3300	3500	4000	4500	5000	1600	2500	3000
Mast extend height H2	mm	2110	3072	3480	3780	3980	4480	2110	2980	3480	3780	3980	4480	5150	5650	2172	3072	3572
Min. fork height H3	mm	90						90
Driving speed（laden/unladen）	Km/h	3.5/4.0						3.5/4.0						4.5/5.0		4.5/5.0
Lift speed（laden/unladen）	mm/s	90/130						90/130
Lowering speed（laden/unladen）	mm/s	95/120						95/120
Brake		Electromagnetic						Electromagnetic
Driving motor	Kw	0.75						1.2						1.2		1.2
Lift motor	Kw	2.2						2.2						3		2.2
Battery capacity/voltage	Ah/V	95/24						95/24, 165/24						165/24		165/24
Battery weight	kg	51						51						160		160
Service weight（without battery）	kg	570	620	645	670	695	720	560	640	665	675	690	720	920	960	585	670	700

Do you offer customized products?

we do custom products and projects.

If you are unable to findyour exact product within our wide variety please call or sales team to see ifthey are able to source the product you require. We also have a team whomanufacturer.
I don' have drawing or picture available for the custom products, could you design it for me?

Yes, we can make the best suitable design for you but do need to know the details - such as a) dimension b) loading capacity c)stackability d)operation environmen.
